Engine Mount Kit - Gen 3 Chevy Inline 6 (194/230/250)

Experience easy installation and customization with our trim-to-fit engine mounts, designed for a seamless fit with 194, 230, and 250 engines (see related items for 292 mounts). These mounts come as a fully TIG-welded set or as a ready-to-weld DIY kit.

With a 3" bushing center offset from the block mounting surface and frame plates extending 6" from the bushing center to the opposite edge, these mounts are engineered for secure and precise positioning. Choose the "Add two frame filler plates" option if you’d like a pair of 10-gauge plates to weld between the frame tab plates.

Each kit includes:

- Two engine mounts with sturdy 1/4" main plates (passenger side mount is taller for 194/230/250 engines)

- Four trim-to-fit 3/16" frame plates

- High-quality large bushings

- Driver-side top hole spacer

- All essential grade 5 zinc-plated hardware for long-lasting durability

Note: These mounts are not compatible with the 235ci inline 6 engine.
