Gauge Mount Adapter – 2-5/8 Inch to 2-1/16 Inch – Black

Gauge mounting adapter designed to simplify updating dash panels that were originally cut for larger 2-5/8 inch gauge openings. This adapter drops directly into the existing hole using a keyed backing that automatically centers the adapter, allowing smaller 2-1/16 inch gauges to be installed without additional fabrication.

Manufactured from fiber-reinforced composite material, the adapter offers excellent temperature resistance, strength, and impact durability. Once installed, the adapter stands slightly proud of the panel for a clean, finished appearance. Three beveled mounting points allow the adapter to be secured using screws or rivets.

• Adapts 2-5/8 inch panel openings to accept 2-1/16 inch gauges
• Fiber reinforced composite construction
• Black finish
• Keyed backing for automatic centering
• Outer diameter: 3.5 inches
• Inner diameter: 2.068 inches
• Total depth: 0.250 inch
• Stands proud of panel: 0.150 inch
• Three beveled mounting points, 0.143 inch diameter
• Mounting points spaced 3 inches on center
• Fasteners not included
