Pedal Pad Mounting Kit

Buy 10 of one part number, get 10% off.

Buy 40+ to get them for 40% off! Sorry, no additional discounts applicable.

A unique and easy to install pedal pad bracket that makes adjusting the pedal pad angle and ratio simple.

Pedal Mount with stainless brackets and hardware for great looks. This mount makes it easy to install pedal pads on brake and clutch arms – simply drill two holes in the pedal arm. Mounts on under-floor pedals or swing pedals. Positive lock allows the foot angle to be adjusted. Slotted pedal pad mounting hole provides adjustable leverage. The floor slot can be smaller because the mount is easy to remove from the pedal arm.

From the center of the 1/4″ holes to the lowest point of the slot is 5/16″, and to the top of the slot is 1-5/16″. On the extended kit, the top of the slot is 1-3/4″ from the center of the 1/4″ holes.

The clutch pedal pad bracket kit bends in the opposite direction as the kits pictured.

I installed a pedal pad bracket on our ’32 – check out the article.
Click here for the instruction sheet.
