Swing Mount Brake and Clutch Pedal Assembly – Adjustable Ratio

Swing-mount brake and clutch pedal assembly designed for custom, street, and competition vehicles requiring precise pedal feel and adjustable brake bias. This forward-facing, hanging pedal setup incorporates an adjustable-ratio brake pedal with an offset clutch pedal, allowing flexible placement and tuning for driver preference and vehicle setup.

The brake pedal ratio is vertically adjustable to provide 5.50:1, 5.88:1, or 6.25:1 leverage, allowing the balance between pedal effort and feel to be tuned. An integrated balance bar allows fine adjustment of front-to-rear brake bias and features positive detent stops at each full turn to maintain consistent adjustment. The balance bar can be locked in place with the included jam nut or used with an optional remote adjuster for quick changes.

Constructed with a lightweight aluminum frame and high-strength, reinforced I-beam style forged pedal arms, the assembly is finished in durable black E-coat. Non-skid waffled pedal pads are laterally adjustable from 5 to 7 inches on center to suit driver ergonomics. A pin and clevis pushrod attachment system minimizes misalignment for smooth, bind-free operation throughout the full range of pedal travel.

This pedal assembly is designed to accept three Wilwood 2.25 inch vertical-mount, single-outlet master cylinders—two for brakes and one for clutch—which are available separately in multiple bore sizes and configurations.

• Swing-mount brake and clutch pedal assembly
• Forward-facing hanging pedal design
• Adjustable brake pedal ratio: 5.50:1, 5.88:1, 6.25:1
• Integrated balance bar with positive detent stops
• Balance bar lockable with jam nut
• Offset clutch pedal
• Lightweight aluminum frame
• Reinforced I-beam style forged pedal arms
• Black E-coat finish
• Non-skid waffled pedal pads
• Pedal pad spacing adjustable from 5–7 inches on center
• Pin and clevis pushrod attachment system
• Accepts three Wilwood 2.25 in. vertical-mount single-outlet master cylinders (sold separately)
